| Place of Origin | China (Mainland) |
| Model Number | ZDAD01B-00 |
| Condition | New |
| Dimension(L*W*H) | / |
| Weight | 123 KG |
| Automatic Grade | Automatic |
| Power | 50KW |
| Voltage | 220v |
| Year | / |
| Machinery Capacity | 100PPM |
| Product Keywords | PACK line,battery line, automatic PACK line |
1 .Battery Pack Information:
1.1. batteries
1) Cell type: 18650; Cell size: Φ 17.8 ~ 18.5 mm; Height 64.8~65.4 mm;
2) Feeding method: manually load the cell into the cell material box;
1.2 current-carrying slices
1) Current carrier shape: branch chip stamping;
2) Thickness of current carrier: 0.15mm to 0.25mm;
1.3 cover up and down
1) Maximum size: 300mm×400mm
2) Number of cells: ≤100
2.Electric bicycle battery packaging wiring design. Type of battery pack for manufacture and acceptance:
1) Pack size: ≤L 220mm* ≤W 200mm*≤ H 300mm
2) Module weight: ≤15kg
3) PACK Weight: ≤30kg
4) Weight of upper and lower covers: ≤30kg
3.Party A's standard plant environmental requirements:
Workshop ground electrostatic: ≤10 to the power of 8;
Workshop anti-static treatment: need to do professional anti-static treatment, the equipment grounding and electrostatic grounding separate
Workshop dustproof grade: 1 million (general environment);
Workshop environment: temperature 0~45℃, humidity 20%~60%;
Air source requirements: inlet pressure > 0.7MPa, dew point temperature <5℃;
Production line power supply: three-phase five-wire AC380V±10%; Frequency: 50Hz;
The incoming power supply shall provide reliable ground wire;
Floor cement thickness (use of fixed bolts) : 300mm
Floor effective height: above 4 meters
Ground flatness: 2m±2mm
