12PPM/min Lithium Battery Production Line Pole Plate Welding Machine

1
MOQ
Negotiation, email communication
Price
12PPM/min Lithium Battery Production Line Pole Plate Welding Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Lithium Battery Production Line
Stable: 97%
Warranty: 1 Year
Voltage: AC220±10%
Qualified: 99.50%
Speed: ≥12PPM/min
High Light:

12 PPM/min Lithium Battery Production Line

,

AC220 Lithium Battery Production Line

,

AC220 lithium ion battery production line

Basic Infomation
Place of Origin: China
Brand Name: ZeCheng
Model Number: ZBCA02A-00
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 90 Working day
Payment Terms: L/C, T/T
Supply Ability: 10 sets per months
Product Description

12PPM/min Lithium Battery Production Line Pole Plate Welding Machine



1 pole sheet welding machine description



This equipment is mainly used for automatic welding of pole piece and pole lug, and it is processed by process bonding. The use of crystal vibrating laser head can effectively improve the working efficiency. Automatic pole plate, automatic pole lug, automatic positioning, automatic laser welding, reduce manual work intensity, improve work efficiency.



2. Design requirements



2.1. Efficiency: 6PM (manual refuelling time not included). Crystal oscillator head laser machine hit about 100 points, it takes about 8 seconds.



2.2. Reliable equipment, low maintenance rate, convenient maintenance and durable;



2.3. Automatic pole lug, automatic pole plate and laser automatic welding pole lug, high efficiency;



2.4. Accurate positioning, stable welding quality, and adjustable welding position;



2.5. Fabrication accuracy of pole sheet (welding position accuracy) : longitudinal: ±0.25mm; Transverse: ±0.50mm;



2.6. The equipment shall have the following functions: flattening, spot welding and automatic taping;



2.7. The welded pole ears are automatically fed into the standard box;



2.8. The welding shall be firm, non-adhesive, in the right position and with high efficiency;



2.9. The maximum of the back end of the adhesive tape shall not exceed 0.4mm;



3. Main components of equipment



The serial number

System composition

The system configuration

Brand or treatment

The number of

1

Rack system





1 set of

Welded skeleton construction

40 x40x3 party

1

The base plate

Black phosphating of steel plate

1

2

Rotating table system





1 set of

CAM splitter



Texaco

1

Stepper motor

R control

1

3

Pole plate feeding box





1 set of

Can seasoning box

Anodized black aluminum parts

1

4

Pole ear feeding box





1 set of

Can seasoning box

Anodized black aluminum parts

1

5

Feeding jacking system





3 sets of

Linear motor

Taiwan gen



3

6

Manipulator system





3 sets of

Servo motor



panasonic



3

Ball screw

silver

3

Linear guide

silver

6

Vacuum suction cups

M, m

6

7

Positioning fixture





6 sets of

Positioning fixture

Anodized black aluminum parts

6

8

Pressure system





1 set of

Gas-liquid booster cylinder

Taiwan

1

9

Laser machine





1 set of

Crystal oscillator laser machine



United win

1

10

Encapsulates the system





1 set of

cylinder

SMC

4

Linear guide



silver

8

11

Receiving box





1 set of

Can seasoning box



Anodized black aluminum parts

1

12

Control system





1 set of

PLC

omron

1

Touch screen

Kunlun state

1



4.Main equipment components



The equipment consists of rack system, rotary table system, pole plate feeding box, pole ear feeding box, feeding jacking system, manipulator system, positioning fixture, laser machine, coating system, feeding box and electrical control system. Rack baking paint color warm gray
