Nickel zinc battery 12V120Ah nickel-zinc composite battery
Properties:
High Energy density
zinc nickel battery energy density can reach: 100Wh /kg, much higher than lead acid battery, nickel hydrogen battery 30Wh/kg-60Wh /kg, more portable, occupy less space;
High discharge rate
zinc-nickel battery has excellent discharge performance at high current, with discharge rate greater than 100C (A). Compared with other batteries, the battery only has A discharge rate of 25C-40C, which can provide more lasting power under the same discharge capacity.
Quick charge
zinc-nickel battery can be charged within 2 hours during quick charging, which is faster than the previous lithium ion battery in 2-4 hours and lead-acid battery in 6-8 hours
Wide range of working temperature
Zinc-nickel battery to adapt to the temperature range :-40 ~55, excellent temperature suitability is very important to battery performance, will not occur combustion explosion, battery activity is still very good at low temperature,-20 can release 90% of the normal temperature,-40C can release 60% of the power
Green environmental protection
zinc nickel battery main raw materials are zinc, nickel, copper, etc., other raw materials are non-toxic and pollution-free, its production and use process does not produce toxic and polluting substances. Fully in line with the national and world environmental protection trend;
Safe and reliable
zinc nickel battery even in extreme conditions, including external short circuit, puncture, fall, extrusion, overcharge, etc., and even the shooting battery itself will not burn, explosion, to ensure the personal safety of users;
Recyclable
it is with the same Recovery value after the end of value Battery life
| The project name | UNIT | The battery pack 12V120Ah |
| The battery type | Zinc-nickel battery | |
| Monomer battery | PCS | 8 |
| Unit size (L * W * H) | MM | 50 * 115 * 250 |
| The connection method | In series | |
| Module form | ||
| Management system BMS | Do not contain | |
| Nominal voltage | V | 13.2 |
| Nominal capacity | AH | 120 |
| Working current | A | 0-240. |
| Charging current | A | 60-3 |
| Battery operating voltage | V | 9.6-15.2 |
| Module size | MM | |
| Battery case size | MM | 400 * 120 * 248 |
| Total battery mass | KG | |
| Charging time | H | 4-10 |
| Charging temperature | ℃ | 0 to 40 |
| Working temperature | ℃ | -25 TO 65 |
1. New equipment promise
Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.
2. Confidentiality commitment
Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.
3. After-sales service commitment
(1) Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;
(2) After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh
(3) During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
FAQ
Q1: Are you factory or trading company?
A: We are factory, with our R&D team, production department, from battery welding machine, etc design , drawing, process, assembly,commission, and final package and shipping.
Q2: Do you accept customization?
A2: YES. we accept customized machine. our strong R&D with 10+year rich experience can do customization.
Q3: About Price?
A3: Price is negotiable. It can be changed according to each battery welding or sorting machine internal configuration ,and also your order quantity.
Q4: About delivery?
A4. Standard welding machine can be delivered within 10days. Customized battery assembly machine can be delivered within 40days or negotiable.
