High Efficiency Laser Sealing Machine Large Cutting Machine 1500KG Weight
1. Product introduction:
The cutting machine is applied to the lithium battery positive and negative electrode sheet single sheet length and chasing point cutting. Continuous cutting, automatic unwinding tension; Put the wheel full use of stainless steel, reduce the surface of chloride ion, affecting the quality of the battery. This machine adopts PLC and touch screen control, easy to operate and strong anti-interference.
2. Equipment features:
2.1. Suitable for cutting copper foil, aluminum foil, battery electrode, insulating material, etc. The technology of this machine is in the leading level in China.
2.2 the machine adopts automatic constant tension control anti-winding, synchronous motor feeding, high-precision color sensing positioning, PLC program control, man-machine interface, it can arbitrarily set cutting length, quantity, speed and other parameters, cutting effect without burrs.
3. Technical parameters:
The serial number | Technical parameters | |
1 | Input power | AC220V |
2 | Power | 500 w |
3 | Dry air | 0.3-0.4MPa |
4 | Cutting width | 500mm |
5 | Maximum cutting speed | 1-20m/min |
6 | Cutting precision | ±0.2mm |
7 | Accuracy of fixed length | ±0.2mm |
8 | Unwinding tension | 0-25n |
9 | Qualified rate of equipment products | ≥98% (except defective number and poor operation caused by raw materials) |
10 | Equipment productivity | 4-6ppm (pole length < 300mm, related to manual proficiency). |
11 | Equipment failure rate | ≤5.0% (except for equipment failure caused by raw materials) |
Cooperation commitment
1. New equipment promise
Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.
2. Confidentiality commitment
Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.
3. After-sales service commitment
(1) Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;
(2) After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh
(3) During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
