1,Weighing and batching system (mixing of lithium battery anode and cathode materials, electronic weighing batching system, fully automatic batching of lithium battery)parameter.
| NO. | Ingredients ability | Batching accuracy | The largest ingredients |
| 1 | 5T/H | 0.2% | 1000KG |
2. Typical materialsZe cheng automatic blending system, soft magnetic magnetic materials mixing material system, lithium batteries ternary material mixing material, PVC weighing mixing material, leather material mixing system, liquid raw materials weighing mixing material, coating material mixing system, BB fertilizer weighing material mixing system, rubber automatic mixing material system, foliar fertilizer mixing system, additive material mixing system, feed weighing batching system, fertilizer weighing line with mixing raw material.
3,characteristics
Weighing batching is widely used in chemical industry, steel, grain, dock and other industries.With the improvement of factory automation, the automatic weighing and batching system has the reliability, stability and report traceability, which replaces the traditional manual operation and eliminates the economic loss caused by the wrong operation. Therefore, weighing and batching plays an extremely important role in the production process.
4. Composition of batching system
1,Raw material delivery system (usually equipped with bag-opening station, bag-opening station for small bags of 25kg, or bag-opening station for ton bags)
2 material conveying system (1 positive pressure pneumatic conveying 2 negative pressure vacuum feeding 3 bucket lifting machine feeding 4 pipe chain feeding)
3,Storage bin system (determine the material and volume of the storage bin according to the type of raw materials, material properties and ratio, etc.)
4,Batching system (type: increment method, decrement weight loss method.Conveyance: belt, screw, vibration, etc.)
5. Downstream mixer (conical mixer, disc mixer)
