220V Lithium Battery Production Line

Negotiation, email communication
220V Lithium Battery Production Line
Features Gallery Product Description Request A Quote
Stable: 97%
Speed: ≥60PPM/min
Qualified: 99.5%
Weight: 900KG
Voltage: 220V
Pressure: 0.6-0.7mpa
High Light:

lithium ion battery pack assembly line


die cutting machine


220V Lithium Battery Production Line

Basic Infomation
Place of Origin: China
Brand Name: Zecheng
Model Number: ZC-SY-03
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 100 Working day
Payment Terms: L/C, T/T
Product Description

Lithium Battery Production Line Experimental microtome


1. Product introduction:


The cutting machine is applied to the lithium battery positive and negative electrode sheet single sheet length and chasing point cutting. Continuous cutting, automatic unwinding tension; Put the wheel full use of stainless steel, reduce the surface of chloride ion, affecting the quality of the battery. This machine adopts PLC and touch screen control, easy to operate and strong anti-interference.


2. Equipment features:


2.1. Suitable for cutting copper foil, aluminum foil, battery electrode, insulating material, etc. The technology of this machine is in the leading level in China.


2.2 the machine adopts automatic constant tension control anti-winding, synchronous motor feeding, high-precision color sensing positioning, PLC program control, man-machine interface, it can arbitrarily set cutting length, quantity, speed and other parameters, cutting effect without burrs.


3. Technical parameters:


NO. Technical parameters
1 Input power AC220V
2 Power 500 w
3 Dry air 0.3-0.4MPa
4 Cutting width 500mm
5 Maximum cutting speed 1-20m/min
6 Cutting precision ±0.2mm
7 Accuracy of fixed length ±0.2mm
8 Unwinding tension 0-25n
9 Qualified rate of equipment products ≥98% (except defective number and poor operation caused by raw materials)
10 Equipment productivity 4-6ppm (pole length < 300mm, related to manual proficiency).
11 Equipment failure rate ≤5.0% (except for equipment failure caused by raw materials)


220V Lithium Battery Production Line 0

Cooperation commitment

1. New equipment promise

Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.

2. Confidentiality commitment

Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.

3. After-sales service commitment

(1)Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;

(2)After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh

(3)During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
