Semi Automatic Car Battery Production Line Positive Negative Die Cutting Machine

1
MOQ
Negotiation, email communication
Price
Semi Automatic Car Battery Production Line Positive Negative Die Cutting Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Stable: 97%
Speed: ≥12PPM/min
Qualified: 99.50%
Weight: 600KG
Voltage: AC220±10%
Warranty: 1 Year
Work Rate: 10W
Compressed Air: ≥ 0.6mpa
High Light:

Die Cutting Car Battery Production Line

,

Semi Automatic Car Battery Production Line

,

Car Battery Die Cutting Machine

Basic Infomation
Place of Origin: China
Brand Name: ZeCheng
Model Number: ZC-AA-29
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 90 Working day
Payment Terms: L/C, T/T
Supply Ability: 10 sets per months
Product Description

Semi Auto Car Battery Production Line Positive Negative Die Cutting Machine


Lithium Battery Production Line Laboratory battery pole cutting machine is developed by zecheng company, which is suitable for experimental or small batch production.The equipment USES the principle of gas-liquid supercharging to convert the small air pressure into large hydraulic output.The equipment appearance is beautiful, the design is scientific and reasonable, the operation is simple and convenient, the mold can be customized according to the customer's requirements.The operation is between manual and automatic, suitable for coil and sheet materials;Manual continuous feeding, automatic discharging, and automatic waste separation;No burr, powder, indentation and other quality defects;It is convenient and fast to replace the die (the life of die is about 30,000 times);Easy to operate, safe and reliable, beautiful appearance, small volume.
1. Main features:
1.1, the use of infrared positioning device, accurate and convenient pole plate positioning die cutting;
1.2, It is convenient and fast to replace the cutting die;
1.3, Long life of die, normal use ≥ 30,000 times;
1.4 , no burr, powder, indentation and other quality defects;
1.5, between manual and automatic, high efficiency of 800 ~ 2000 pieces/hour;(according to the size of pole cutting pieces, 1 to 8 pieces can be punched each time, and the standard is 2 pieces)
1.6. Adopt the structure of four guide columns, smooth up and down sliding with high precision;
1.7. The feeding port of the equipment is equipped with a safety light curtain, which makes the operation very safe;
1.8. Exquisite appearance, solid geometric design, simple and beautiful;
1.9, easy to operate, safe and reliable, small size
2. Performance indicators and basic configuration
2.1. Power supply: 100v-240v /60Hz
2.2. Work rate: 10W
2.3. Compressed air: ≥ 0.6mpa
2.4. Applicable specifications: maximum punching and cutting size: 250x250mm (the maximum punching and cutting size can also be unlimited according to customer requirements)
2.5. Battery plate thickness thickness: 0-0.5mm
2.6. Booster cylinder: 5T
2.8. Feeding method: manual
2.9. Equipment capacity: 800-2000ea /H
2.10. Punching and cutting accuracy: ±0.1mm
2.11. Weight: about 120KG
2.12. Volume product: 550X450X900mm
cooperation commitment
1. New equipment promise
Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.
2. Confidentiality commitment
Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.
3. After-sales service commitment
(1) Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;
(2) After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. En
(3) During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
