No.
|
Item
|
Parameters
|
Remarks
|
|
1
|
Unwinding device
|
3-inch core inflatable shaft
|
MAXφ600mm
|
|
2
|
Film guide mechanism
|
φ30mm
|
|
|
3
|
Film tension adjustment device
|
0－10Kg
|
|
|
4
|
Winding device
|
3-inch core inflatable shaft
|
MAXφ650mm
|
|
5
|
Rewinding correction device
|
Correction and alignment accuracy is less than 0.5mm
|
Linear mobile rectifying mechanism
|
|
6
|
Servo motor drive
|
Rack and electric control box
|
|
|
7
|
Rack and electric control box
|
Color card: GSB05-1426-2001 (instead of GSB G51001-94), 61 R02 Vermilion
|
|
|
8
|
Electronic control device
|
PLC
|
|
|
9
|
touch screen control panel
|
5.7 inches
|
|
|
10
|
Pneumatic components
|
SMC
|
|
|
11
|
Maximum mechanical speed of winder and unwinder
|
50m/min
|
|
|
12
|
Specifications of the machine
|
1700×800×1050
|
|
|
13
|
Splicing stage
|
One plate and two cylinders
|
|
|
14
|
vacuuming
|
Vacuum system
|
optional
|
