20 PPM Laser Sealing Machine

1
MOQ
Negotiation, email communication
Price
20 PPM Laser Sealing Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Stable: 97%
Speed: ≥12PPM/min
Weight: 2500KG
Warranty: 1 Year
Voltage: AC220±10%
Name: 20 PPM Laser Sealing Machine
High Light:

battery weight machine

,

battery sealing machine

,

20 PPM Laser Sealing Machine

Basic Infomation
Place of Origin: China
Brand Name: ZeCheng
Model Number: ZC-AA-466
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 90 Working day
Payment Terms: L/C, T/T
Supply Ability: 10 sets per months
Product Description

20 PPM Laser Sealing Machine For Cleaning Cylindrical Battery 18650 Dirt



Used for cleaning dirt such as iron scrap, dirt, electrolyte and other dirt on the surface of cylindrical battery 18650 after sealing, cleaning drying water droplets twice, spraying anti-rust oil and drying.



2. Equipment action flow



Connect the seal into the battery → one brush (warm water can add cleaning agent) → one cut water → two high pressure rinse (without cleaning agent) → two cut water



→ transition → air drying → baking → transition → shell surface spray code → transition → spray anti-rust oil → baking → discharge.



3: technical parameters of the equipment

The basic parameters
Single machine efficiency P 120 PPM
Chain linear velocity Variable frequency adjustable 0-3m/Min
Product pass rate 99.50%
Device rotation rate 98%
Standard water consumption Recycle 10L of water in an hour for 1000 batteries
The noise 80 db or less
Plant configuration
The compressed air Acuity 0.6 MPa
The input voltage 380 v / 50 hz, 25 kw
Tap water Provide 1 inch water pipe interface to the equipment installation bit
Waste water discharge Provide 1 inch waste water discharge pipe interface to the equipment installation bit



4. Main components of the equipment



NO The name of the The content is introduced
1 Feeding and docking mechanism 1 set, connect with the sealing machine to pull the material out.
2 Conveyor chain 2 sets, stainless steel chain, battery support on the iron roller, iron roller and ladder type rubber friction, drive the battery rotation, ensure the uniform cleaning and oil consistency; The conveyor chain is driven by variable frequency speed regulating motor.
3 Scrub institutions 1 set, continuously pump out high pressure water when brushing, flat brush mechanism, divided into brush main body, brush both ends. 1# tank hot water spray battery when scrubbing.
4 Cut the water agencies 2 sets, 1 set after washing and 1 set after washing. Adopt 1 vortex fan.
5 Baking institutions Two sets, the use of whirlpool fan with the heat pipe, the battery before and after oil baking, the battery surface temperature ≤60℃
6 Printing mechanism 1 set. After cleaning and drying, the shell surface is sprayed with imaz 9030
7 Oil institutions 1 set, using a spray gun to spray oil, rust agent must use water - soluble rust agent. The spray gun is made of oil mist by precise pressure regulating valve.
8 Tank body Two sets, two stainless steel water tank completely independent, with two stainless steel water pumps, automatic water supply, automatic drainage. Stainless steel float level gauge, automatic detection of water level; When the high pressure flushing, the pump pump water by the nozzle to flush the battery cap and rolling groove.
9 rack It's divided into two sections. The first section is for scrubbing, rinsing and cutting water. The second part is oil drying. The sealing chain part is made of 304# stainless steel, the others are square baking paint.
10 The man-machine interface 1 set, rotate the man-machine interface.
