1. Introduction of equipment principle
Insert the batteries into the whole process before welding needle emissions into the feed channel flows to the end, pushing cylinder pushing the battery to the welding station, touch the spot welder sensor, automatic welding, the welding is completed, tape pull out of the battery (for copper cathode of ear needle stick welding is real can't pull out the needle automatically, you pull out the), automatic needle, pull last downstream lala take out battery.
2. Device action sequence
| Place the spot-welding batteries in rows in the feeding tank |
|
When the tank flows to the end, the battery enters the spot welding position mechanism |
|
Trigger sensor for automatic welding |
|
Automatically pull out the needle and pull out the tape |
3 equipment composition
3.1. Feeding mechanism
3.2. Push the battery into spot welding mechanism
3.3. Spot welding mechanism
3.4. Transmission mechanism
3.5. Needle pulling mechanism
3.6. The overall structure is as follows
3.6.4 safety part
3.6.4.1 pull belt emergency stop button of main feed.
3.6.4.2 control part.
3.6.4.3 equipped with fault alarm and reset function.
3.6.4.4 emergency stop switch.
3.6.4.5 in addition to the automatic mode, all operations must also have manual mode, and can conveniently switch the automatic or manual mode.
3.6.4.3 the compressed gas or nitrogen interface shall be equipped with a pressure reducing valve to adjust the pressure.
3.6.5 electrical configuration
3.6.5.1 operating voltage 220V/50HZ/3PHASE. Control voltage 24V DC.
3.6.5.2 the protection class of all electrical components such as: motor, inductor, solenoid valve and trip switch is IP54
3.6.5.3 the protection class of the power distribution cabinet button is IP65.
3.6.6 installation site requirements
3.6.6.1 the user shall provide a separate distribution switch and be responsible for the connection of power supply outside the equipment.
3.6.6.2 installation area conditions (provided by party a).
3.6.6.3 power supply: ac 220V, frequency: 50±1HZ.
3.6.6.4 compressed air: 0.4-0.6mpa.
3.6.6.5 amount of compressed air: 30L/ hour.
3.6.6.6 power consumption: 0.2kw/hour.
3.6.6.7 be sure to ground.
3.6.7 technical parameters
3.6.7.1 equipment capacity/speed: ≥40PPM(take 18650 as an example).
3.6.7.2 qualified rate of equipment products: ≥ 99.9%.
3.6.7.3 equipment failure rate: ≤ 0.5% (caused by equipment only).
1. New equipment promise
Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.
2. Confidentiality commitment
Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.
3. After-sales service commitment
(1) Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;
(2) After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh
(3) During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
