1. Device functions:
Process before
1.1 devices function: battery magnet suck the whole emissions into the feed end pull belt belt into pushing cylinder push the battery to the roll groove location after the core under axial compression roller CAM slot by wheel by living cells feed forward roll groove after rolling groove on discharging bring, repeat the next cycle. Structure: feeding zone, push the battery into the roll slot mechanism, core shaft, roller slot, feed of CAM mechanism, machine the machine size. Roll slot size stability, low energy consumption. The noise is small, easy to operation.
1.2 after years of technical research, strong technical team cooperation, exclusive research and development, the battery shell coating will not fall off after the rolling groove; In the groove rolling mechanism, we adopt CAM feed, which is not affected by the change of air pressure, and micrometer adjustment to ensure the size.
2. Equipment composition:
2.1 physical picture of equipment:
Equipment structure drawing
2.2 pull-up belt mechanism:
2.2.1 push the battery into the roller slot mechanism.
2.2.2 upper mandrel mechanism.
2.2.3 roll slot
2.2.4 feed CAM mechanism.
Basic equipment parameters and detailed description
3.1 equipment capacity/speed :≥30-40 PPM.
3.2 qualified rate of equipment products: ≥98%
3.3 equipment failure rate: ≤5% (failure caused by equipment only)
3.4 power source: 380V/ 1.2kw
3.5 gas source: 0.6 ~ 0.8mpa
Applicable products: 18650/21700 steel shell cylindrical battery
According to customer's requirements (please refer to the following dimensions)
1. New equipment promise
Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.
2. Confidentiality commitment
Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.
3. After-sales service commitment
(1) Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;
(2) After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh
(3) During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.
