Laboratory Ultrasonic Spot Welder

Negotiation, email communication
Laboratory Ultrasonic Spot Welder
Features Gallery Product Description Request A Quote
Stable: 97%
Speed: ≥12PPM/min
Qualified: 99.50%
Weight: 800KG
Power: 5.5KW
Ound Output Frequency: 40kHz
High Light:

automatic liquid filling machine


pressure leak detector


5.5KW Liquid Injection Machine

Basic Infomation
Place of Origin: China
Brand Name: ZeCheng
Model Number: ZC-AA-3
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 90 Working day
Payment Terms: L/C, T/T
Supply Ability: 10 sets per months
Product Description

Liquid Injection Machine Line 5.5kw Laboratory ultrasonic spot welder

1. An overview of the


In order to be convenient to use, PLC is used as a program for group control, and the welding parameters of 0-99 groups of different models are stored respectively, and the corresponding group of diao can be run.


Note: adjust the appropriate parameters, press the "ok" key to run. If the welding effect of a group is not good, the parameters can be modified separately without affecting other parameters. To overcome the tedious operation of changing models in the production process, the parameters of each model can be stored after the successful product debugging and alignment welding. When welding a certain product, the corresponding parameters can be called up and run.


High temperature resistance, no welding accessories.


Ultrasonic metal welding is an efficient welding method,


2. Structure and working principle


The machine consists of five parts: electric system, pneumatic system, energy changing system, power system and frame.


The machine working principle is: to produce ultrasonic with piezoelectric ceramic transducer, high conversion efficiency, stable performance, through the preparation applying high frequency vibration welding hot welding of metal parts, metal workpiece surface and internal molecular rub against each other, making contact with the two components of the temperature rise sharply, as the temperature and touch clean enough to make metal internal molecular change, contact surface between the two weldments is to produce a melting layer, and the vibration stopped, in the holding time, welding head to absorb heat, accelerate the weldment cooling, welding to form a uniform


3. Technical parameters


3.1 supply voltage: power frequency ac 220V (+5%-10%), 50/60hz


3.2 air pressure: air source greater than 0.6mpa


3.3 maximum output power: 800W


3.4 power regulation range: 55%-85%


3.5 sound output frequency: 40kHz


3.6 effective working stroke of welding head: 20mm


3.7 apparent power of transducer: 800W


3.8 preloading time: 0.01 -- 9.99s adjustable


3.9 welding time: 0.01 -- 9.99s adjustable


3.10 curing time: 0.01 -- 9.99s adjustable


4. Comparison table of model and specification of ultrasonic metal spot welder:



Rated power (W) 800 1000 3000 1000
Operating frequency (KHZ) 40 20 20 20
Power supply (V) 220 220 220 220
Welding time (S) 0~9.99 0~9.99 0~9.99 0~9.99
Welding material (MM)

0.05 ~ 0.1 copper foil

0.05 ~ 0.25 aluminum foil

0.05 ~ 0.2 aluminum nickel belt

0.05 ~ 0.2 copper foil

0.1 ~ 0.3 aluminum foil

0.05 ~ 0.2 nickel piece

0.1 ~ 0.4 copper foil

0.1 ~ 0.6 aluminum foil

0.1 ~ 0.3 nickel piece

0.1~0.6 stainless steel sheet

0.05 ~ 0.2 copper foil

0.1 ~ 0.3 aluminum foil

0.05 ~ 0.2 nickel piece

Pressure (Mpa) 0.3 ~ 0.5 0.3 ~ 0.5 0.35 ~ 0.6 0.3 ~ 0.5



Cooperation commitment

1. New equipment promise

Our company guarantees that the goods provided to customers are brand new, complete and unused equipment.

2. Confidentiality commitment

Our company promises that without the written permission of any party, the other party's related drawings, technical information, business information and other business secrets and technical secrets must not be leaked to third parties in any way.

3. After-sales service commitment

(1)Two months from the date of shipment of the equipment, Party B is responsible for non-human faults in a timely and free warranty within one year (when the equipment is faulty, the after-sales service staff will respond within 2 hours after receiving the notification. According to the situation, personnel must be in place within 48 hours. No later than 60 hours, to ensure the continuity of production by the buyer;

(2)After the equipment has passed the warranty period, if there is a problem, the two parties communicate and deal with it. If necessary, after-sales personnel will be sent to repair it, and only the cost will be charged. Zh

(3)During the warranty period stipulated in the contract and technical agreement signed by the two parties, the company will provide a warranty for quality problems that are not caused by human damage during the normal use of our products.

Laboratory Ultrasonic Spot Welder 0Laboratory Ultrasonic Spot Welder 1Laboratory Ultrasonic Spot Welder 2
